Forklift Starters - The starter motor these days is typically either a series-parallel wound direct current electric motor which consists of a starter solenoid, that is similar to a relay mounted on it, or it can be a permanent-magnet composition. Once current from the starting battery is applied to the solenoid, mainly through a key-operated switch, the solenoid engages a lever which pushes out the drive pinion that is located on the driveshaft and meshes the pinion with the starter ring gear that is found on the engine flywheel.
When the starter motor starts to turn, the solenoid closes the high-current contacts. As soon as the engine has started, the solenoid has a key operated switch that opens the spring assembly to pull the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This permits the pinion to transmit drive in only a single direction. Drive is transmitted in this method via the pinion to the flywheel ring gear. The pinion continuous to be engaged, like for instance for the reason that the operator fails to release the key as soon as the engine starts or if the solenoid remains engaged as there is a short. This actually causes the pinion to spin separately of its driveshaft.
This aforementioned action stops the engine from driving the starter. This is an essential step in view of the fact that this kind of back drive would enable the starter to spin very fast that it can fly apart. Unless modifications were made, the sprag clutch arrangement would preclude making use of the starter as a generator if it was made use of in the hybrid scheme discussed earlier. Normally a regular starter motor is designed for intermittent use that will stop it being used as a generator.
The electrical parts are made to be able to function for more or less 30 seconds so as to stop overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical components are designed to save cost and weight. This is actually the reason nearly all owner's manuals intended for vehicles suggest the operator to pause for at least ten seconds right after each ten or fifteen seconds of cranking the engine, whenever trying to start an engine which does not turn over immediately.
The overrunning-clutch pinion was launched onto the marked in the early part of the 1960's. Before the 1960's, a Bendix drive was utilized. This particular drive system functions on a helically cut driveshaft which has a starter drive pinion placed on it. As soon as the starter motor begins spinning, the inertia of the drive pinion assembly allows it to ride forward on the helix, therefore engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear enables the pinion to exceed the rotating speed of the starter. At this instant, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.
The development of Bendix drive was made in the 1930's with the overrunning-clutch design called the Bendix Folo-Thru drive, developed and launched during the 1960s. The Folo-Thru drive consists of a latching mechanism along with a set of flyweights in the body of the drive unit. This was an enhancement in view of the fact that the typical Bendix drive used to be able to disengage from the ring as soon as the engine fired, even if it did not stay running.
When the starter motor is engaged and starts turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. When the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for instance it is backdriven by the running engine, and then the flyweights pull outward in a radial manner. This releases the latch and enables the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement could be prevented previous to a successful engine start.
